Landoll Industrial Tag Trailers
Landoll Industrial tag trailers are designed with the highest quality and durability in mind for more capacity. Each trailer of this family features a standard bucket trough saving approximately 13″ in height with the recessed trough.
Industrial Tag Model L2024A
Superior Quality Long Lasting Industrial Tags
The L2024A is a 20,000 lb. capacity (26,000 GVWR) trailer for hauling of backhoes, skid steers, rollers, and other construction equipment. The L2024A offers a 19′ flat deck and a 5′ beavertail. Trailer is constructed of 4″ Jr. I-Beams on 16″ centers 80,000 PSI yield material. 8″ deep formed side rails and 2 10,000 lb. axles with 3″ spring suspension are also standard. More standard features are a pierced main beam for a low 35″ deck height, bucket trough, ten combination stake pocket/chain gotchas, and powder coat paint finish.
Specifications
| MODEL | CAPACITY | BASE WEIGHT | DECK | AXLES | TIRES & PLY RATING |
|---|---|---|---|---|---|
| L2024A | 10 Ton | 5,900 lbs. | 24′ | 2 | 235/80R 16 LRE |
Industrial Tag Model L2424A
24,000 lb. Capacity
The L2424A is a 2 axle 24,000 lb. capacity tag trailer designed to haul a variety of construction equipment. The trailer is constructed with 4″ Jr. I-Beams 80,000 PSI material for the crossmembers and 8″ formed side rails. Standard features include ten combination stake pocket/chain gotchas, bucket trough and powder coat paint finish.
Specifications
| MODEL | CAPACITY | BASE WEIGHT | DECK | AXLES | TIRES & PLY RATING |
|---|---|---|---|---|---|
| L2424A | 24,000 lbs. | 6,000 lbs. | 24′ | 2 | (8) 235/80R 16 LRE |
Industrial Tag Model L4024A
40,000 lb. Capacity
The 40,000 lb. capacity L4024A features a loaded deck height of 32″ by design of a pierced main beam. Standard suspension is 40,000 lb. multi-leaf spring, while the brakes are 12.25×7.5 Full Air ABS, 4S2M. Other standards are a bucket trough, ten combination stake pocket/chain gotchas built into the frame and durable powder coat paint finish.
Specifications
| MODEL | CAPACITY | BASE WEIGHT | DECK | AXLES | TIRES & PLY RATING |
|---|---|---|---|---|---|
| L4024A | 20 Ton | 8,500 lbs. | 24′ | 2 | (8) 215/75Rx17.5 Double Coin LRH |
Industrial Tag Model L5024A
40,000 lb. Capacity
The 40,000 lb. capacity L5024A features a loaded deck height of 32″ by design of a pierced main beam. Standard suspension is 40,000 lb. multi-leaf spring, while the brakes are 12.25×7.5 Full Air ABS, 4S2M. Other standards are a bucket trough, ten combination stake pocket/chain gotchas built into the frame and durable powder coat paint finish.
Specifications
| MODEL | CAPACITY | BASE WEIGHT | DECK | AXLES | TIRES & PLY RATING |
|---|---|---|---|---|---|
| L5029A | 25 Ton | 10,200 lbs. | 102″ | 3 | (12) 215/75R x 17.5 Double Coin LRH |
